Model |
ZPG-500 |
ZPG-750 |
ZPG-1000 |
ZPG-1500 |
ZPG-2000 |
ZPG-3000 |
ZPG-8000 |
|
Working volume(L) |
300 |
450 |
600 |
900 |
1200 |
1800 |
4500 |
|
Heating area (m2) |
6 |
7.6 |
9.3 |
12.3 |
14.6 |
15.3 |
18.08 |
|
Stirring speed (rpm) |
6-30 stepless speed adjustment |
||||||
|
Power(kw) |
4 |
5.5 |
5.5 |
7.5 |
11 |
15 |
22 |
|
Mezzanine design pressure (hot water)(Mpa) |
≤0.3 |
||||||
|
Vacuum degree inside the cylinder(Mpa) |
-0.09-0.096 |
||||||
Vacuum paadle dryer Feature:
During the drying process of the vacuum rake dryer, the rake teeth rotate continuously in positive and negative directions, which has strong applicability, and the dried materials are stirred evenly and dried quickly. Because it uses jacket heating and vacuum exhaust, it is suitable for almost all materials of different properties and states, especially for explosive and oxidizable materials; the products it produces are of high quality, easy to operate, and can recover volatile gases. The pollution to the environment is reduced, and the heat source consumption is relatively small.
Application of vacuum rake drying
The Heat Sensitive Materials Vacuum Rake Dryer is designed for various paste, slurry, powder, fiber, granular and other materials. The transmission part adopts a durable and stable cylindrical gear reducer. The driving shaft and rake teeth are made of high Strength One-piece casting or internal heating thick-walled rake teeth can fully guarantee the stable operation of the vacuum rake dryer in various harsh working environments. And two or four percussion rods can be added inside its shell to facilitate the rapid drying and crushing of materials. Its heating medium can have a variety of options, such as: steam, heat transfer oil, hot water, etc.
