Feature:
1.Made of high-quality austenitic stainless steel, all corners are arc transitioned, no dead ends, no residues, no concave and convex surfaces, and exposed screws.
2.The inner and outer surfaces are highly polished, and the inner surface roughness of the inner surface reaches Ra≤0.2μm, and the outer surface is treated with matte finish, and the roughness reaches Ra≤0.4μm, which is easy to clean.
3. PLC control system, the operation can be automatically completed according to user requirements by setting process parameters, and all process parameters can be automatically printed, and the original records are true and reliable.
4.Meet the GMP requirements for pharmaceutical production.
|
Type |
GHL-10 |
GHL-50 |
GHL-150 |
GHL-200 |
GHL-250 |
GHL-300 |
GHL-400 |
GHL-600 |
|
Volume (L) |
10 |
50 |
150 |
200 |
250 |
300 |
400 |
600 |
|
Capacity (kg/batch) |
3 |
15 |
50 |
80 |
100 |
130 |
200 |
300 |
|
Blending speed (rpm) |
300/210 |
300/210 |
270/180 |
270/180 |
188/130 |
160/110 |
120/85 |
120/80 |
|
Blending power (KW) |
1.5/2.2 |
4/5.5 |
9/11 |
11/14 |
11/14 |
11/14 |
15/17 |
22/30 |
|
Cutting power (KW) |
0.85/1.1 |
1.5/2.2 |
2.4/3 |
3.3/4 |
3.3/4 |
4.5/5.5 |
6.5/8 |
9/11 |
|
Cutting speed (rpm) |
1440/2900 |
|||||||
|
Working time (min) |
8-15 |
|||||||
|
Particle size (mesh) |
20-80 |
|||||||
