Working Method
Chickpea grinding machine pulverizer with big capacity powder pulverizer machine uses the high-speed relative movement between the movable blade and the fixed blades to crush the material by the impact of the teeth, shear, friction and collision between the materials to achieve the purpose of crushing materials. Crushed materials by the role of rotating centrifugal force and the induced fan, into the cyclone separation chamber, after the fan off the material, dust into the pulse dust box, through the filter cartridge after recycling. The size of powder particle size can be obtained by choosing different aperture screen.
Main features
1)When capacity is low, single mill machine is very suitable.
2)The single mill is easy to clean, simple in structure and few occupied space.
3)Price is low,it can also solve the problem of tight budget.
4)Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.
|
Model |
MMJ-400 |
MMJ-630 |
MMJ-1000 |
MMJ-1200 |
|
Capacity(kg/h) |
100-300 |
20-500 |
300-800 |
400-1000 |
|
Feed size(mm) |
≤20 |
≤25 |
≤30 |
≤30 |
|
Crush size(mesh) |
20-100 |
20-100 |
20-100 |
20-100 |
|
Grinding Motor (kw) |
18.5 |
30 |
45 |
55 |
|
Discharge power (kw) |
0.75 |
0.75 |
1.5 |
1.5 |
|
Fan motor (kw) |
11 |
15 |
22 |
37 |
|
Main speed(rpm) |
4500 |
4300 |
3500 |
3000 |
|
Dimensions (L*W*H mm) |
5400×1100×2700 |
6800×1300×2900 |
7800*1600*3200 |
8800*1800*3500 |
|
Weight(kg) |
900 |
1500 |
1900 |
2200 |
Composed of feed hopper, main motor, and milling chamber. The material is crushed into powder inside the crusher chamber. Then enter the cyclone discharge section.
You can change differenr size of screen to get different size of powder. From 20-100mesh.
Cyclone Discharge Part
Help to Separate dust from powder.Due to the action of the fan, the interior of the cyclone is in a vacuum state. The powder will be continuously discharged through the discharge motor. Some too fine powder will enter the dust removal box. Avoid dust entering the room. Meet GMP standards.
The dust removal box can collect dust. It contains a needle punched anti-static cloth bag. When the dust enters the dust removal box, it adsorbs on the surface without any surface. Then the pulse air hammer will automatically hit the bag and cause it to fall off. You can open the valve at the bottom of the box every day to clean it.
